Medium and High Power Laser Cleaning Machine

Short Description:

Laser cleaning machine is the latest high-tech product. Easy to install, operate, easy to achieving automation.


Product Detail

Product Introduction

Laser cleaning machine is the latest high-tech product. Easy to install, operate, easy to achieving automation. Plug in power, turn on and start cleaning - without chemicals, media, dust, water.
Cleaning with no detergent, no media, no dust, no water. Auto focus, can clean curved surface, gentle cleaning surface. Cleaning resin, oil stain, rust, coating materials, paints on workpiece surface

Technical Parameters

Model ML-MF100I-LC ML-MF200I-LC ML-MF500I-LC ML-MF1000I-LC ML-QF-WS-JX-HW2000
Laser Power 100W 200W 500W 1000W 2000W
Cooling Way Air Cooling Water cooling
Laser Wavelength 1064 nm
Power Supply AC 220-250V / 50 Hz AC 380V / 50 Hz
Maximum KVA 500W 2200W 5100W 7500W 14000W
Fiber Length 3m 12-15m 12-15m 12-15m 12-15m
Dimension 460x285x450mm 1400X860X1600 mm 2400X860X1600mm+
555X525X1080mm (external chiller size)
Focal length 210mm
Focal depth 2mm 5mm 8mm
Gross Weight 85kg 250kg 310kg 360kg Total 480kg
Handheld Laser Head Weight 1.5kg3 kg
Working Temperature 5-40°C
Pulse width 20-50k ns
Scan Width 10mm-80mm (customizable additional price) Don't exceed 100m 120mm
Laser frequency 20-50k HZ
Laser source type Fiber laser source
Options Portable/ Handheld/ Handheld/ Handheld/ Handheld/
Handheld Automation/ Automation/ Automation/ Automation/
Robotic system Robotic system Robotic system Robotic system

Comparison with traditional clean methods

Comparision

Laser Cleaning

Chemical Cleaning

Mechanical Grinding

Dry ice cleaning

Washiing Method

non-contact cleaning

contact cleaning

Abrasive contact cleaning

non-contact cleaning

Harm to base material

None

Yes

Yes

None

Washing Efficiency

High

Low

Low

Mid.

Consumable

Power

Chemical Detergent

Abrasive paper, grinder, abrasive stone

Dry Ice

Washing result

Very good, very clear

Medium, uneven

Medium, uneven

Good, uneven

Precision Washing

Accuracy controllable. High precision

Uncontrollable, low precision.

Uncontrollable, medium precision.

Uncontrollable, poor precision.

Safety/Environment

No pollution

Chemical pollution

Dust pollution

No pollution

Operation

Easy to operate, portable or automation optional.

Complicated process, higher technical requirement of the operator. Pollution prevention measures required.

Need more time & manpower. Pollution prevention measures required.

Easy to operate, portable or automatic.

Investment

High investment on machine. But no consumable, low maintenance cost

Low investment on machine. But expensive consumables

Medium investment on machine. High man-power cost.

Medium investment on machine. High consumable cost.

Core Features

1. First high power fiber laser cleaning machine in China.
2. Non-contact cleaning,can be no damage to workpiece
3.Precision positioning, selective cleaning, desired cleaning area can be applied to the workpiece.
4. No need chemical detergent, no consumable. Safe & environment-friendly.
5. Easy to operate, either portable or equipped with robot for automatic cleaning.
6. High cleaning efficiency, time-saving.
7. Stable laser cleaning system, free maintenance.

abbrere
20220426175732

Application Scenarios

qignx4r (1)
qignx4r (2)
qignx4r (6)
qignx4r (4)
qignx4r (3)
qignx4r (5)
